VEHICLE MOUNTED PTZ IP CAMERA
VT-P300S
New product
Smart Function: Fisheye Dewarping, 4K Resolution, ANPR (Automatic Number Plate Recognition), face detection, people counting,Tripwire Analytics.
More info
Vehicle Mounted PTZ IP Camera consists of HD visible light cameras, laser ranging, dynamic organization, precision gears, digital decoder, high-performance image processing unit and controller. All-reinforced structural design, super-strength stainless steel center bearing, multi-round reinforcement design, to ensure the equipment run properly under the condition of the vehicle bump.
Simple mechanical design and compact structure, exquisite; high positioning accuracy and reliability; operating flexibility, speed, start and stop smoothly, easy to control. Internal industrial embedded control electronics system, control zoom, focus, video switching, pan tilt rotate. Whole shell is made of super alloy, the internal material uses high strength stainless steel bearings, to meet anti-shock requirements for military wheeled car, reach IP66 grade, to ensure that equipment long-term operation in harsh outdoor environment.
Sepcifications:
|
Model/Series : |
VT-P300S |
|
|
Camera parameters : |
Image Sensor |
1/2.8" Progressive CCD |
|
Effective Pixels |
1920[H]*1080[V] |
|
|
Signal to noise ratio |
55dB |
|
|
BLC |
automatic / manual |
|
|
Day and night |
automatic / manual |
|
|
Lens focal length |
8.1mm-310mm |
|
|
Drive mode |
Video [DC drive] |
|
|
Lens aperture |
F1.8 |
|
|
Detection distance |
20~500m |
|
|
Coding compression : |
main processor |
Hi3516 |
|
Compression standard |
H.265/H.264 High Profile /MJPEG |
|
|
Stream parameters |
32K~20Mbps |
|
|
Audio compression |
G.711 |
|
|
Audio bit rate |
64Kbps |
|
|
Network Interface : |
Mobile phone monitoring |
Support Windows Mobile,Symbian,iPhone Platform smartphone monitor |
|
Network protocol |
PPPoE,DHCP,TCP/IP,HTTP,RTP/RTCP,RTSP,UPNP,SMTP,FTP,ONVIF |
|
|
WIFI/satellite |
Optional support for 802.11b / g protocol, 2.4GHz or military satellite channel |
|
|
4G/5G module |
Optional internal or external EVDO/WCDMA/TD-SCDMA modules |
|
|
Network Interface |
10M/100M adaptive Ethernet port |
|
|
Alarm interface |
Support/optional |
|
|
Management mode |
IE / standalone management software/NVR/decoder/CMS platform server/third-party management platform |
|
|
Networking information |
Wired/wireless [WIFI/spread spectrum microwave/4G/satellite, etc.] |
|
|
support SDI/CVI/IP or analog multi-mixed mode networking |
||
|
Laser specifications [Optional] : |
Laser power |
1KM [8W] optional |
|
Laser wavelength |
808nm/940nm |
|
|
Laser angle |
Synchronize motion adjustment with camera zoom |
|
|
PTZ specifications : |
Load mode |
Vertical device |
|
Horizontal speed |
0.01~100°/s |
|
|
Vertical speed |
0.01~30°/s |
|
|
Rotation angle |
0~360° |
|
|
Cruise/scan |
6 articles |
|
|
Automatic homing |
support |
|
|
Preset position |
256 |
|
|
Vertical angle |
+40°~-75° |
|
|
Cover material |
Aluminum alloy, stainless steel lock, window: transparent glass; top open-top design, easy to install the equipment |
|
|
Shield size |
18 inch, 23 inch, 29 inch single window shield [depending on the type of matching] |
|
|
Temperature control |
Built-in automatic thermostat,-35℃~65℃ |
|
|
Other : |
Protection class |
IP66 |
|
Input voltage |
AC24V/DC24 |
|
|
Power consumption |
≤60W |
|
|
Peripheral power supply |
Optional solar and wind power supply system |
|
|
equipment weight |
15KG |
|
